Aluminum Strip

» Aluminum Strip

  • Aluminium Capping Strip

    CATEGORY AND TAGS:
    Aluminum Strip , ,

    Alloy: 5052

    Temper: H49

    Thickness: 0.18 and 0.16 mm (excluding lacquer)

    Tolerances: +/- 0.020 mm

    Width: 29.0 mm

    Tolerances: +/- 0.2 mm

    enquiry
    • Specifications

    Many people out of the aluminium industry would easily mistake the aluminium capping strip for aluminum coil sheet for ropp caps at the first sight. Since there’s the word “capping”, it’s understandable for some people to think this way. In addition to sheet and roll types, there do be strip and tape types of aluminium for ropp caps. While used for ropp caps, the aluminium strip is usually of 8011 h14, 8011 h16 and 3003 h16.

    While most of the time the aluminium capping strip is used in suspended ceilings made from mineral fiber panels. It covers the connection between two panels and enhances the appearance of the ceiling support structure. Most of the time the strip is coated by a coating system which ensures a perfect surface finish and optimum paint adhesion, even at the tight bend radii on the edges. Narrow and thin-gauge painted strips are also applied to the visible surfaces of the T-shaped construction rails. In addition, an aluminium capping strip helps to strengthen the support power for two adjoining ceiling panels.

    aluminium capping strip manufacturer and supplier

    We supply aluminium capping strip of the following specifications:

    Alloy: 5052

    Temper: H49

    Thickness: 0.18 and 0.16 mm (excluding lacquer)

    Tolerances: +/- 0.020 mm

    Width: 29.0 mm

    Tolerances: +/- 0.2 mm

    Inside diameter: 406 mm

    Outside diameter: Max 1,800 mm

    Coating on front side: Single coat of polyester lacquer

    Coating on reverse side: Protective lacquer coating

    We are an 11-year supplier (till 2019) and 20-year manufacturer of aluminium metal strips. We also supply aluminium strips for cables, fins, transformers and so on. Welcome to send inquiries by leaving a message, sending an email or chatting online with us!
