    Haomei supplies aluminum coil width 3000mm, 2500mm width aluminum coil and aluminum coil width 2 of ordinary specifications. Other widths include 1500mm, 1600mm, 1700mm, 1800mm, 1900mm and 2000mm. Special specifications can be customized. These coil rolls are also known as ultra wide aluminum coil products.

    enquiry
    • Specifications

    Haomei supplies aluminum coil width 3000mm, 2500mm width aluminum coil and aluminum coil width 2 of ordinary specifications. Other widths include 1500mm, 1600mm, 1700mm, 1800mm, 1900mm and 2000mm. Special specifications can be customized. These coil rolls are also known as ultra wide aluminum coil products.

    2500mm 3000mm 2 width aluminum coil

    Alloy Temper Thickness Width Application
    1050 F、O、H12、H14、H16、H18 、H22、H24、H26、H28 0.2-8mm 100-2650mm CTP/PS version base, aluminum plastic board, lamp material, battery explosion-proof valve and tabs
    1060 F、O、H12、H14、H16、H18 、H22、H24、H26、H28 0.2-8mm 100-2650mm Power battery soft connection, aluminum plastic boards, lamp materials, capacitor shells, road signs, building exterior walls
    1070 F,O,H12,H14,H16

    H18,H19,H22,H24

    H26,H28,H111,H112,H114

    0.2-8mm 100-2650mm Radiator, charging pile, anti-corrosive insulation, wire and cable protection net, aluminum bus, electronic products, oxide materials, etc.
    1100 F,O,H12,H14,H16

    H18,H19,H22,H24

    H26,H28,H111,H112

    0.2-8mm 100-2650mm Aluminum-plastic panels, bus doors, cookware, curtain walls, heat exchanger
    3003 F,O,H12,H14,H16

    H18,H19,H22,H24

    H26,H28

    0.2-8mm 100-2650mm Mobile phone battery shells, lighting, interior decoration
    3004 F,O,H12,H14,H16

    H18,H19,H22,H24

    H26,H28,H112,H114

    0.2-8mm 100-2650mm Lamp base, blinds, wide curtain wall panels, LCD back panels, aluminum substrates for color coating, etc.
    3005 F,O,H12,H14,H16 H18,H19,H22,H24

    H26,H28,H112,H114

    0.2-8mm 100-2650mm Lamp base, shutters, curtain walls, substrates for color coated aluminum
    3104 F,O,H12,H14,H16

    H18,H19,H22,H24

    H26,H28,H111,H112,H114

    0.2-8mm 100-2650mm Lamp base, blinds, cans, oxidizing materials, substrates for color coated aluminum
    3105 0.2-8mm 100-2650mm Bottle caps for alcohol, beverage, cosmetics, color coated aluminium coil
    5052 F、O、H111、H12、H14、H16、H18、H22、H24、H26、H28、H32、H34、H36、H38 0.2-8mm 100-2650mm Aluminium tread plate, umbrella ribs, transport vehicle
    5083 0.5-8mm 100-2650mm Auto parts, high voltage switches, ship boards, tank trucks
    5182 F,O,H12,H14,

    H16,H18,H19,

    H22,H24,H26,

    H28,H32,H34

    H36,H38,H111,

    H112,H114,H116,H321

    0.2-8mm 100-2650mm Ship outer plates, decks, refrigeration devices, tank cars, oxygen generator towers, auto parts
    5086 0.2-8mm 100-2650mm Automobile, oxidizing material, fuel tanks, coal gondola, doors
    5754 F、O、H111、H12、H14、H16、H18、H22、H24、H26、H28、H32、H34、H36、H38 0.2-8mm 100-2650mm High-speed rail noise barriers, vehicle tank  materials, alloy doors and windows, etc.
    6061 F,O, T4, T6, T651 0.3-8mm 100-2650mm Vehicle wall cladding, flooring
    8011 H14、H16、H18、H19 0.012-0.5mm 100-1600mm Bottle caps for wine, pharmaceutics, cosmetics, beverage

    Our ultra-wide and ultra-thick plates are featured by internal stress elimination non-invariant shape, with the maximum width of 2650mm and maximum thickness of 500mm.

    Ultra-wide coil aluminium rolls are a special type in aluminum products. Generally those of width over 1500mm are regarded as wide aluminum plates or coils, and those over 2000mm super wide aluminium sheets or coils, which not all manufacturers are able to produce because of restriction of process and technology.

    In terms of production equipment, aluminum coil width 3000mm, 2500mm width aluminum coil and aluminum coil width 2 m have higher requirements on rolling amplitude width. From the manufacturer’s point of view, there are higher requirements for the production capacity of the manufacturing enterprise, and the performance should be stable in a wide range. At present, only a part of large-scale manufacturers with strong strength can meet the production requirements. At present, the commonly used ultra wide aluminum sheet coil alloys in the market are mainly 5 series and 6 series, and the commonly used alloys are 5052-h112, 6061-T6, etc. the prospect of ultra wide aluminum coil sheet is bright, which has a great market space in some emerging strong industries such as shipbuilding, auto parts, electronic equipment, precision machinery etc.
