Aluminum Coil

» Aluminum Coil

  • 1060 Aluminum coil

    CATEGORY AND TAGS:
    Aluminum Coil

    Grade:1000 Series, 1060
    Temper:O-H112
    Type: Coil, roll
    Application:  electric and chemical equipment, railroad tank cars, etc.
    Thickness:0.1-30mm

    enquiry
    • Specifications

    Properties of 1060 Aluminum Coil

    1060 aluminum sheet/coil is pretty similar to 1050 aluminum alloy with more than 0.1% of aluminum by weight. Both 1050 and 1060 aluminum sheet/coil of Mingtai Al. lives up to ISO standards, but they cover different ASTM standards. 1060 aluminum sheet/coil contains 0.05% cooper, thus, its conductivity is 55%. Besides, 1060 aluminum sheet/coil is relatively low strength, essentially pure aluminum alloy with many different tempers, such as O (annealed), H12, H14, H16, H18, etc. what’s more, other aluminum sheet belonging to commercial pure wrought family are available, including 1050, 1070, 1100 and so on and so forth. We can produce 1060 aluminum coil of thickness from 0.1 to 30.0mm with good cutting performance and corrosion resistance.

    Elements Si Fe Cu Mn Mg Cr Zn Ti Others Al
    Content

    (max)

    0.25 0.35 0.05 0.03 0.03 0.05 0.03 0.15 Remain
    Alloy
    Temper
    Specified Tensile
    strength
    Yield
    strength
    Elongation
    Thickness(in.) (ksi) (ksi) (%)
    1060-O

    (annealed)

    0.006-0.019 8.0-14.0 2.5 Min15
    0.020-0.050 Min22
    0.051-3.000 Min25
    1060-H12/

    1060-H22

    0.017-0.050 11.0-16.0 9.0 Min6
    0.051-2.000 Min12
    1060-H14/

    1060-H24

    0.006-0.019 12.0-17.0 10.0 Min1
    0.020-0.050 Min5
    0.051-1.000 Min10
    1060-H16/

    1060-H26

    0.006-0.019 14.0-19.0 11.0 Min1
    0.020-0.050 Min4
    0.051-0.162 Min5
    1060-H18/

    1060-H28

    0.006-0.019 Min16.0 Min12.0 Min1
    0.020-0.050 Min3
    0.051-0.128 Min4


    1060-H112

    0.250-0.499 Min11.0 Min7.0 Min10
    0.500-1.000 Min10.0 Min5.0 Min20
    1.001-3.000 Min9.0 Min4.0 Min25


    Features and Applications of 1060 Aluminum Coil

    1060 aluminum sheer/coil is noted for its excellent welding characteristics and formability by cold or hot working with commercial techniques. It cannot be hardened by heat treatment but only from cold working. Tempers H12, H14, H16 and H18 are determined by the amount of cold working imparted into the alloy. Moreover, 1060 aluminum sheer/coil has good corrosion resistance as well as poor machine-ability, and its machine-ability can be improved in harder (cold working) tempers, such as H16 and H18. For its features above, 1060 aluminum sheet/coil has a vast application, such as electric and chemical equipment, railroad tank cars, etc.
